Product Details:
|
| Material: | ASTM HSLAS-F GR50 T=2.0+/-0.02mm | Fabrication Type: | Rapid Sheet Metal Bending, Stamping |
|---|---|---|---|
| Tolerances: | 0.50mm - 0.75mm | Finishing: | Painting, Coating Or Other Customized |
| QC System: | 100%-Dimensional Inspection Strictly | Capability: | Prototype Bending, Low Volume Production |
| Highlight: | motorcycle sheet metal prototype,Short lead time sheet metal prototype,0.75mm sheet metal prototype |
||
ASTM A1011 HSLAS HRPO GR50 material is a suitable choice for making bending prototype parts at Metalstar Prototype. It is a type of high-strength, low-alloy steel that is hot-rolled, pickled, and oiled. The "GR50" designation indicates that it has a minimum yield strength of 50 ksi (345 MPa), and this material has several properties that make it well-suited for prototype bending applications:
| Steel Material Properties | |||||||||
| Material Grade/Description | Chemical Composition (weight %) | Tensile strength (Mpa) |
Yield strength (Mpa) |
Elongation | Remarks | ||||
| (C) | (P) | (Mn) | (S) | (Si) | |||||
| ASTM A1011 HRPO HSLAS-F GR50 | 0.20 | 0.03 | 1.30 | 0.04 | …. | >=450 | >=340 | >=17% | Baoshan steel Gr50 |
High Strength: The HSLAS GR50 grade provides a good balance of strength and formability, which is crucial for complex bending operations. The higher yield strength allows for thinner gauge materials to be used, reducing material costs and weight.
Formability: The hot-rolled and pickled surface finish of ASTM A1011 HSLAS HRPO GR50 gives it excellent formability characteristics. This allows the material to be bent and formed into complex shapes without cracking or tearing.
Availability: As a common and widely-used steel grade, ASTM A1011 HSLAS HRPO GR50 is readily available from many steel suppliers. This ensures that Metalstar Prototype can quickly source the material as needed for prototype projects.
Cost-effectiveness: Compared to some specialized alloys, ASTM A1011 HSLAS HRPO GR50 is a relatively cost-effective material choice for prototype bending applications.
Overall, the combination of high strength, good formability, availability, and cost-effectiveness make ASTM A1011 HSLAS HRPO GR50 an excellent material selection for the prototype bending services offered by Metalstar Prototype. This grade provides the necessary performance characteristics while also being practical and economical for short-run prototype parts.
